Divers know it all too well: barotrauma epidemics occurring on a liveaboard or on long dive trips
are not due to the interference of some supernatural entity, they are due to equalisation mistakes.
For all we know, the infamous Ghost of Dead Corals—the main suspect behind electrical
anomalies and mysterious boat sinking—does not mess with divers' ears.

Unnatural condition

Equalising while the ambient pressure is rapidly increasing is not an ability required in the natural
environment of humans as land animals. We need to equalise mechanically only in particular
conditions, such as in the landing phase of an aircraft or during a descent down the water column.
Coming down a mountain on foot we don’t need to equalise. Jumping off the top Mt. Eiger’s north
face could possibly cause a need to equalise, but nature appears to have weeded out the genes of
those who might at one point or another in human evolution have consented to participate in such
an experiment. Undoubtedly some divers can equalise with ease, almost without realising it. Who
knows if they are descended from populations who ventured underwater, or the forgotten offspring
of those who headed down off the Eiger?

The art of equalisation
As scuba divers we breathe constantly through a regulator, which allows us to maintain our lungs
at their normal volume and use any equalisation technique at any depth. Moreover, our use of the
Frenzel and hands-free techniques is aided by the air coming into the oral cavity from the
regulator. We have it easy. The true artists and high priests of equalisation are found in freediving.
Freedivers don’t breathe through a regulator. For them, the Valsalva manoeuvre stops working at
depths as shallow as 10 metres. To use the Frenzel and hands-free techniques, freedivers need to
move air from their lungs into their oral cavities first by a variety of techniques, depending on the

Valsalva, an overrated technique
The best known and most utilised technique among scuba divers is snubbed by freedivers due to
its limited potential. It takes its name from Antonio Maria Valsalva, an Italian anatomist of the 17th
century. He was also the first to note that this manoeuvre affects the pressure of the intrathoracic
system and the heart. The Valsalva manoeuvre is now considered one of the causes that
encourage the migration of microbubbles from one atrium to another in divers with a PFO (Patent
Foramen Ovale). However, this isn’t why freedivers snub it: Because the lungs of freedivers are
compressed at depth, abdominal pressure can no longer be used to further reduce the lung
volume at depths as shallow as ten metres, making this technique impossible to use.

Doctor Frenzel’s invention
Two and a half centuries later, in 1938 to be precise, Ears Nose & Throat (ENT) specialist Dr.
Hermann Frenzel, an officer in the German Luftwaffe, developed a technique which he taught to
Stuka pilots, the infamous dive bombers. In this technique, the tongue comes into play by pushing
air upward and toward the back of the palate, so that the volume decreases. Since the glottis is
closed, the pressure increases. The soft palate is open, and the nostrils are closed. The increased
pressure in the nasal cavity then induces the eustachian tubes to open. In some people, the
opening of the tubes is eased by a mechanical effect that allows the tubes to open at a lower
The Frenzel manoeuvre can be performed in two different ways. The first relies 100% on pressure
generated by the movement of the tongue. The second uses 50% pressure and 50%
biomechanics: The tubes open due to the movement of the tongue and the contraction of the
upper nasopharyngeal. In either version, the Frenzel manoeuvre reduces the stress on the middle
ear and the equalisation effort.

On land, the gesture of pinching the nostrils between thumb and forefinger usually signals an
unpleasant smell. Underwater and among divers, the same signal means something completely
different: The instructor, or the buddy, is reminding us to equalise. This simple signal can induce a
misconception: Many divers don't know that with a little practice, it is possible to equalise without
even touching the nose. Using the hands-free technique, the diver opens the soft palate, which
allows air from the regulator (at ambient pressure) to fill the nasal cavity and mechanically open
the tubes. During descent, the pressure inside the middle ear and the ambient pressure are
equalised automatically.
We’ve already described three techniques here, but for freedivers willing to exceed depths of 30
m, this may still not be enough. These divers rely on their own advanced versions of the Frenzel
manoeuvre and the hands-free technique, and ultimately something called the mouth-fill
technique. In the latter, the freediver uses their mouth and cheeks as a compressor to push air
toward the middle ear.
The diver’s position
Except in the no-limits discipline, freedivers always dive head-down. Scuba divers can afford to
descend (and equalise) more comfortably in a feet-down or horizontal position. It should be noted
that using the Valsalva manoeuvre in a head-down position can be harmful to a diver due to an
increased risk of overpressurising and congesting the diver’s middle and inner ear.

The pace of equalisation
While we learn to listen to our bodies better with practice and over time, equalisation mistakes can
persist. Even though the textbooks are very clear about equalising before we feel discomfort, how
many times did we need to be reminded by our ears?
Speech therapy for divers
Learning to control the muscles in its body is an ancient challenge for homo sapiens. In order to
walk upright, speak, sing, type, or play the piano, our body requires precise coordination between
our muscular system and the nervous system. In speech therapy, patients learn to become aware
of the functions and actions of muscles and organs involved in forming speech. This aspect of
speech therapy has become an integral part of the training of divers seeking to improve their
performance and safety during descent. Who would have thought that moving and controlling the
tongue, or forming the “T,” “Ka” and “N” sounds underwater, could make your ears safer and more

About the author
DAN Member since 1997, Claudio Di Manao is a PADI and IANTD diving instructor. He's the
author of a series of books and novels about diving, including Shamandura Generation, an
exhilarating portrait of Sharm el Sheikh's diving community. He collaborates with magazines,
radios and newspapers, talking and writing about diving safety, marine life and travels.
